| Single output type |
 |
|
| Model: 0055 SERIES (35 Watt.) |
|
| ¡ö |
INPUT VOLTAGE:AC 100-240V |
| ¡ö |
WEIGHT:166g APPROXIMATELY |
|
| ¡ö |
CASE SIZE:45.4mm x 27.8mm x95.4mm |
|
|
| |
|
| |
MODEL |
DC OUTPUT |
|
|
|
|
|
|
|
|
0055-050400 |
5V |
4.0A |
|
|
|
|
|
|
|
|
0055-060350 |
6V |
3.5A |
|
|
|
|
|
|
|
|
0055-070330 |
7V |
3.3A |
|
|
|
|
|
|
|
|
0055-080320 |
8V |
3.2A |
|
|
|
|
|
|
|
|
0055-090300 |
9V |
3.0A |
|
|
|
|
|
|
|
|
0055-100280 |
10V |
2.8A |
|
|
|
|
|
|
|
|
0055-110260 |
11V |
2.6A |
|
|
|
|
|
|
|
|
0055-120250 |
12V |
2.5A |
|
|
|
|
|
|
|
|
0055-130240 |
13V |
2.4A |
|
|
|
|
|
|
|
|
0055-140230 |
14V |
2.3A |
|
|
|
|
|
|
|
|
0055-150220 |
15V |
2.2A |
|
|
|
|
|
|
|
|
0055-160210 |
16V |
2.1A |
|
|
|
|
|
|
|
|
0055-170200 |
17V |
2.0A |
|
|
|
|
|
|
|
|
0055-180190 |
18V |
1.9A |
|
|
|
|
|
|
|
|
0055-190180 |
19V |
1.8A |
|
|
|
|
|
|
|
|
0055-200170 |
20V |
1.7A |
|
|
|
|
|
|
|
|
0055-210160 |
21V |
1.6A |
|
|
|
|
|
|
|
|
0055-220160 |
22V |
1.6A |
|
|
|
|
|
|
|
|
0055-230150 |
23V |
1.5A |
|
|
|
|
|
|
|
|
0055-240150 |
24V |
1.5A |
|
|
|
|
|
|
|
|
|
| |
|
| |
|
